Power Incline
Instantly adjustable incline lets users looking for a more intense workout add challenge at the touch of a button.
Suspension Design
Suspension design provides a smooth, low-impact exercise experience while minimizing noise and maintenance.
Ergonomic Comfort
Large, cushioned pedals reduce stress on joints, while narrow pedal spacing promotes good posture.
Easy Access
An open design and a low step-on height make it easy for anyone to get started and have a stable, secure exercise experience.
Bluetooth & Wi-Fi Enabled
Connect the console to Bluetooth headphones and heart rate monitors for a wireless experience and connect to Wi-Fi for entertainment apps and software updates.
Durability of Design
A heavy-gauge welded steel frame provides excellent stability during intense workouts and durability that withstands years.
User-Defined Workouts
Variable stride length and multi-position handlebars make it totally intuitive for users to get a workout tailored to their body and abilities.
Entertainment Series Console
Now you can make your fitness center a highlight of your offering with exercise that entertains. Our new E Series console will bring people in and keep them coming back with all of their favorite entertainment apps, plus exclusive HD destination footage, HIIT programs, optional live TV and more. Users can even mirror their own devices to stream whatever moves them.
CONSOLE
CSAFE | Yes |
Display | 16” class capacitive touchscreen LCD |
HDMI IN Port | Yes; screen cast of smart devices which support HDMI out to console |
Workouts | Go, manual, Sprint 8, Virtual Active, target heart rate, interval training, fat burn, rolling hills, constant watts, glutes, time goal, distance goal, calorie goal, fitness tests, custom |
Heart Rate | Contact, telemetric & Bluetooth HR |
Languages | English, German, French, Italian, Spanish, Dutch, Portuguese, Chinese-S, Chinese-T, Japanese, Korean, Swedish, Finnish, Russian, Arabic, Turkish, Polish, Welsh, Basque, Vietnamese, Somali, Danish, Thai, Malay, Catalan |
Analog TV | Optional; NTSC, PAL, SECAM |
Digital TV | Optional; ATSC 1.0, QAM-B, ISDB-T, ISDB-Tb, DVB-C/S/S2/T/T2 |
Pro:Idiom Compatibility | Optional; via coax |
Wifi | Yes |
USB Port | Yes; device charging, device media, software updates |
FRAME
Frame Type | Ascent Trainer® |
Variable Stride Length | 51–58 cm / 20”–23” |
Step-on Height | 21.6 cm / 8.5” |
Power Incline | 15%–37% |
Resistance System | 2-stage generator |
Resistance Range | 1-20 |
Pedal Type | Oversized with rubber inserts |
Pedal Spacing | 5.1 cm / 2” |
Handlebar Design | Multi-position dual action with resistance / incline toggles, stationary with contact heart rate grips |
Extras | Water bottle holder, reading rack |
TECH SPECS
Assembled Dimensions | 191 x 89 x 173 cm / 75” x 35” x 68” |
Assembled Weight | 163.5 kg / 360 lbs. |
Max User Weight | 182 kg / 400 lbs. |
Power Requirements | 100–240 V — 50/60 Hz AC |
Power Supply | NEMA 5–15 (requirement may vary outside the USA) |
WARRANTY
*FOR LIGHT COMMERCIAL USE. SOME LIMITATIONS APPLY.
Frame | Home - Lifetime Commercial - Lifetime |
Generator | Home - Lifetime Commercial - 5 Years |
Parts | Home - 7 Years Commercial - 5 Year |
Labor | Home - 2 Years Commercial - 2 Years |
